Ghost Quick Zoom Sliding Scope Adjuster for 20mm Picatinny Rail

Ghost
Code: sld-swtch
£99.99
  • Adjust magnification from a firing grip
  • Integral dual ring mount for 30mm tube optics
  • Works with LPVO and adjustable magnification scopes

If you have ever missed a kill because you had to pull off target to adjust magnification, this mount was designed with you in mind! The Ghost Quick Zoom Sliding Scope Adjuster for 20mm Picatinny Rail allows you to adjust the magnification of any adjustable mag riflescope with a rotary adjuster from a firing grip while you keep your reticle on target! Gone are the days of awkward body mechanics when adjusting your optic, giving you more opportunity to bag those all important kills in game!

The Quick Zoom Sliding Scope Adjuster is constructed almost entirely from CNC machined aluminium with steel cables and a polymer sliding button and can be fitted to any Airsoft rifle with a minimum top rail length of approximately 38cm. A spacer is included for longer setups, keeping the adjustment cables protected from snags, and also included in the box is an upper scope ring segment with a 20mm Picatinny rail built-in, allowing a micro red dot sight to be added to the setup as a backup. This combination of a dual ring scope mount, sliding button, spacer and an MRDS mount gives you a whole lot of alu for your money, and even more skirmish utility!

Full description

Description

The Ghost Quick Zoom Sliding Scope Adjuster for 20mm Picatinny Rail is based on a cutting-edge real steel design that has only just made it to market, showing we Airsofters are right on the tail of the latest real steel trends! The set includes a dual ring scope mount for 30mm tube optics, a sliding scope switch, a rail spacer for longer rail setups and even a 20mm Picatinny rail equipped upper scope ring segment so you can add a micro red dot sight if needed.

The mount, spacer and sliding switch base are constructed from CNC machined aluminium for an immaculate finish and perfect compatibility, keeping the weight low and strength high for a long life of rigorous use. The cables which connect the sliding switch to the mount and your optics' rotary magnification adjustment dial are constructed from steel with a polymer coating to keep the rust away and facilitate worry-free wet weather use. Included with the set are 3 polymer spacers, allowing you to get a snug fit around your magnification adjustment dial for an instant response from the sliding switch and high reliability.

The mount itself is incredibly lightweight thanks to its weight-reduced design, with plenty of unnecessary material removed while maintaining optimum strength. The rings are sized for 30mm tube optics and can be set up with either plain upper ring segments or with one replaced with the included 20mm Picatinny upper ring segment if you want to add a micro red dot sight. While the sliding switch allows for extremely fast and easy magnification changes, mounting a micro red dot means you can engage sudden close range threats far faster than with your primary optic.

To install the setup you will need to first mount the sliding switch assembly in your desired location with the cables protruding through the rear. Next, thread the cables through the channels on the underside of the spacer section if you are using it. With this done, you can thread the cables through the channels on the underside of the scope mount, through the back and onto the runners on the rear of the mount.

Next, install your scope either with the included upper ring segments or the railed upper ring segment if you require it. With your scope in place, you can fit the adjuster ring over your magnification adjuster dial (use the included spacers for a snug fit). Finally, remove the attachment bars on the adjuster ring via the two small Allen bolts on each and slide the cables through the recess, reattaching the attachment bars when the cables are fitted tightly. Any excess cable length can be clipped away using wire cutters or sharp scissors, but make sure you are happy with fitment before you trim the cables. Measure twice, cut once!

The Quick Zoom Sliding Scope Adjuster is ideal for LPVO and rifle scope setups mounted on DMR rifles or other accuracy-oriented setups and makes this type of rifle far more intuitive to use, not to mention scary fast. If you have ever fumbled with your magnification dial at an inopportune moment and missed your chance to take the shot, with the Quick Zoom Sliding Scope Adjuster you will never miss that chance again!

Features

  • CNC Aluminium construction - Polymer coated steel wires, polymer switch
  • Sliding scope switch - Adjust magnification quickly from a firing grip
  • Perfect for DMR rifles and other accuracy focussed setups - Adjust on the fly with minimal movement
  • Integral dual ring mount for 20mm Picatinny rails - 49mm height to optic centre
  • Fits 30mm tube optics with a rotary magnification dial - Ideal for LPVO and 30mm tube rifle scopes
  • Includes 20mm Picatinny rail upper ring segment - Ideal for adding a micro red dot
  • Requires fitting - Cut the cables to the appropriate length for your setup
  • Compatible with variable magnification tube scopes - LPVO and riflescopes with rotary magnification dial
  • Optional spacer included - Suitable for top rails of approx 38cm in length
  • Spacing between mount rings: 11.5cm Approx, measure up before ordering!
  • Direction of adjustment is dependent on your scope - Some will slide forward to increase mag, some the opposite

Package Includes

  • Ghost Quick Zoom Sliding Scope Adjuster for 20mm Picatinny Rail
    • Aluminium 30mm dual ring mount
    • Optional Aluminium spacer
    • Aluminium sliding switch assembly with polymer switch
    • Polymer spacers for different diameter magnification adjustment dials
    • 2x Aluminium Upper ring mount segment
    • Optional Aluminium 20mm Picatinny rail upper ring segment
    • Allen keys
    • Bolts

Special Instructions

We are unable to accept returns on Quick Zoom Sliding Scope Adjusters which have had the cables modified by the user. Please ensure you measure thoroughly if you are cutting the cables. You can also use the Quick Zoom Sliding Scope Adjuster on shorter setups by leaving the cables unmodified, although excess cable will protrude around the magnification dial of your scope.

The Quick Zoom Sliding Scope Adjuster requires 11.5cm of available mount ring space on your 30mm tube optic. It is not compatible with compact riflescopes which taper out to the objective lens with less than 11.5cm between the taper and the eyebell. An example of the type of scope which will not work is the Vector Optics Veyron.

This mount is designed to work best with optics that have an easy-to-move adjustment dial, and if yours is quite hard to move, this may not be ideal for your setup. While easier than using the mag dial itself, this sliding switch will take some practice to master and is also relatively complex to install. We are ready to help, so if you have issues you can get in touch with us or pop into our Showroom where we can lend a hand.

Specification

General

Parts & Accessories Type
External Parts
External Part Type
Mount
Package Includes
Scope mount
Patrol Base - Warning Icon
Warnings
The Quick Zoom Sliding Scope Adjuster requires a 20mm Picatinny rail to mount

Construction

Colour Wheel Greyscale
Item Colour
Black
Construction Icon
Construction
CNC aluminium mount, spacer, upper ring segments and sliding switch base. Polymer switch & magnification dial spacers. Steel wires with polymer coating

Part Specific

Rail System Icon
Rail System
20mm RIS / RAS

Mount Specific

Mount Type
Quick Zoom Sliding Scope Adjuster
