CYMA CM.132S Pistol MOSFET Edition, Black

CYMA CM.132S Pistol MOSFET Edition

Name: CYMA CM.132S Pistol MOSFET Edition
Brand: CYMA
SKU: PR011476
Price: 117.49 EUR
Availability: InStock

Code: …

€128.99

Quantity

High Rate of Fire
Upgraded Gearbox
MOSFET Pre-installed

An Airsoft Electric Pistol which has an upgraded Gearbox with a pre-installed MOSFET, meaning you get a high rate of fire in a pistol which works perfectly in any weather conditions!

Full description

Delivery & Returns

Delivery & Postage

Here at Patrol Base we ship worldwide, delivering not only to the UK but to most of the EU and select Worldwide locations as well. We provide a working day-by-road service via our handpicked courier services, simply buy your Airsoft guns with us and we'll have them delivered directly to your door.

For more information and to see the country we deliver please check out our Delivery Information Page.

Estimates

Below are some rough postage prices for orders. Please note these are subject to change and are only a rough guide. For a more accurate postage estimate please use the Postage Calculator at the basket.

UK Standard

£6.95

Approx.

UK Next Day

£8.95

Approx.

Highlands / Islands

£24.99*

Approx.

Saturday

£14.95

Approx.

* Scottish Highlands, Islands, and EU post prices can vary wildly. Prices range from £8.99 to £29.99, so please ensure you refer to the Postage Calculator at the basket for the lowest possible price.

Returns

We want you to be delighted with our products and services, so we provide the simple Patrol Base guarantee: if on receiving your item you are unhappy with your item for any reason then simply send it back to us. We will replace or refund the item.

You can return any item for any reason whatsoever, even if you have just changed your mind, within 14 days of receipt of the order. This is in addition to your rights under the Consumer Protection (Distance Selling) Regulations 2000.

For more information on returning products, and how to do it please visit our Returns Policy Page.

Description

This Airsoft Electric Pistol accepts standard AEP magazines to make it compatible with any AEP mags you already have. The main feature of the pistol is the MOSFET which makes them easy to run, and higher performance than your typical AEP

It features both Semi and Full Automatic fire modes, which are selected via the Fire Selector on the rear of the Slide. The gun has a safety which can be engaged to prevent the trigger from being pulled. To activate it just move the switch on the offside of the frame.

It also has an adjustable HOP which allows you to backspin the BBs to increase range at the cost of accuracy. To make adjustments, remove the top slide by pulling down the hammer, and pulling the slide forwards and up. The HOP is then adjusted by the gear-style adjustment wheel on the side.

The magazine holds a total of 30rnds which is more than enough to spray at the enemy in a panic, or to make a competitive sidearm for CQB situations. The underside of the frame has a 20mm rail which will accept compatible RIS accessories, such as a . The Outer Barrel is Threaded to accept 14mm CCW Muzzle Devices, such as Suppressors and Tracer Units. Simply unscrew the Thread Protector to access the Thread underneath.

If you're looking for an easy to use and dependable sidearm as a backup or primary weapon for CQB situations, which has consistent performance due to not having to mess around with gas, then the CYMA CM.123S Pistol MOSFET Edition is the perfect sidearm for you.

Features

AEP Replica
Electric Powered Pistol
MOSFET Edition
High Rate of Fire
Semi & Full Auto Fire
Standard AEP Magazines
Trigger Lock Safety
Adjustable HOP
Gear Style HOP Adjust
Alloy Upper Slide
20mm Accessory Rail
Consistent Performance
Perfect CQB Gun
Battery/Charger NOT Included

Package Includes

CYMA CM.132S Pistol MOSFET Edition
30rnd Magazine
Speedloader

External Construction

The externals of the replica are metal where they would be on the real world gun. This includes things like the outer barrel, handguard, and receiver. If a real world gun has polymer parts then the gun will still be marked as full metal externals, examples of this would be an M4, where the Stock and Pistol grip are always made from Polymer.

Safe removal of the slide

As you look at the pistol showing the slide lock / release lever, this is most important in order to not damage the pistols frame. With the pistol in your right hand with the barrel pointing to the left, move this lever downward, it only moves a little bit, but in doing this, it allows the top slide to be moved forward around 5mm, this is crucial in order to remove the top slide correctly without breaking the fragile rear tags that are part of the gun lower frame.

Once you have moved the slide forward on its frame, lift it up and forward to remove it from the pistol, and you can then fit your battery.

To re-fit the slide, please make sure you position the top slide onto the frame in the same forward position, before moving the slide backward into its correct position, once the slide is backward as far as it will go, ONLY THEN, move the slide lock / slide release lever back into position.

DO NOT force the slide straight down onto the gun, doing this will break the two tabs that hold the slide onto the gun, and will invalidate any warranty on the pistol.

All AEP pistols are checked by us before sending to the end user to ensure they are in good condition with the tabs intact as such we would unfortunately be unable to accept the return of the item if it has been damaged in this manner.

Specification

General

Weapon Type	Pistol
Over 18	Yes
Defence / UKARA Required	Yes, No,
FPS (Feet Per Second), using 0.20g BB	Approx. 200fps ± 10%, using 0.20g BB
Site Legal, using 0.20g BB	Yes
Pre-Built	Yes
Included Items	Cleaning Rod Speed Loader
User Skill Level	Regular Player

Weight and Dimension

Weight (KG)	Approx. 0.761kg
Length (Extended)	23cm

Construction

Primary Colour	Black, Tan ,
Pre Two-Toned	No
Construction	Alloy slide and frame, Polymer pistol grips
External Construction	Polymer Alloy
Internal Construction	Polymer Alloy

Weapon Specific

Powered By	Electric
Blowback	None
Weapon Platform	B9
Magazine Style	AEP
Fire Selector	Semi Automatic Full Automatic
Safety Features	Trigger Lock
Shooter Configuration	Right Handed
Weapon Configuration	Standard
Weapon Scale	1:1
Suggested BB Weight	0.2g

Hop-Up

Hop-Up Unit	Yes
Hop-Up Adjuster	Gear
Hop-Up Location	Remove slide to access

Furniture

Furniture	20mm Pistol Rail Rear Lanyard Mount Point Threaded Outer Barrel
Rail System	20mm Pistol Mount
Sight Type	Iron Sights
Sling Options	Lanyard Loop

Barrel

Outer Barrel Thread Type	Male
Outer Barrel Thread Direction	CCW (Counter Clockwise)
Outer Barrel Thread Size	14mm

Magazine Specific

Magazine Type	AEP
Magazine BB Capacity	Approx. 30 Rounds
Magazine BB Fill Method	Speed Loader
Magazine BB Fill Location	Top

Electric Gun Specific Information

Gearbox

Gearbox Wiring	Top Wired

Battery Specific

Battery Connector	Mini-Deans Connector

Compatible Battery

Compatible Battery Type	Li-Po
Compatible Battery Configuration	AEP
Compatible Battery Voltage	7.4v

Pistol Specific

Slide Material	Alloy
Pistol Slide Type	Standard

Product Testing Data

Test Description	200FPS
Tested Using	ASG Blaster 0.20g BBs
Test Date	13/03/20

Detailed Power Tests

FPS

FPS, using 0.20g BB	Approx. 200fps, using 0.20g BB

Size guide

Joule Charts

Special Instructions

These table can be used as a reference to see if the BB weight you are using will be over acceptable Joulage limits at some Airsoft Sites in the UK. To check if the weight can be used chrono your weapon using the BB you intend to use, and then compare it to the chart.

FPS, Power and Joule Limits can vary from site to site, so please get in touch with where you're going to play with in advance to avoid disappointment.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, with a 350fps limit for Automatic Replicas, 400fps for Semi-Automatic Replicas, and 500fps for Bolt Action Replicas.

Tap the tabs below to open the relevant chart for your replica.

This table should be used for reference, and cannot be used to check one weight against another, as the weight of the BB affects the power.

In order to check if the BB can be used with your replica chronograph using the weight you wish to use and then compare it against the table.

Every time you change weights you will need to re-chrono and check against the table. This is not a conversion chart between weights.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, and is the equivalent of 350fps, using 0.20g BB resulting in an upper limit of 1.14j.

Velocity	BB Weight (Grams)
FPS	0.20	0.25	0.28	0.30	0.32	0.36	0.40	0.43	0.45	0.50
250	0.58	0.73	0.81	0.87	0.93	1.05	1.16	1.25	1.31	1.45
260	0.63	0.79	0.88	0.94	1.00	1.13	1.26	1.35	1.41	1.57
270	0.68	0.85	0.95	1.02	1.08	1.22	1.35	1.46	1.52	1.69
280	0.73	0.91	1.02	1.09	1.17	1.31	1.46	1.57	1.64	1.82
290	0.78	0.98	1.09	1.17	1.25	1.41	1.56	1.68	1.76	1.95
300	0.84	1.05	1.17	1.25	1.34	1.51	1.67	1.80	1.88	2.09
310	0.89	1.12	1.25	1.34	1.43	1.61	1.79	1.92	2.01	2.23
320	0.95	1.19	1.33	1.43	1.52	1.71	1.90	2.05	2.14	2.38
325	0.98	1.23	1.37	1.47	1.57	1.77	1.96	2.11	2.21	2.45
328	1.00	1.25	1.40	1.50	1.60	1.80	2.00	2.15	2.25	2.50
330	1.01	1.26	1.42	1.52	1.62	1.82	2.02	2.18	2.28	2.53
335	1.04	1.30	1.46	1.56	1.67	1.88	2.09	2.24	2.35	2.61
340	1.07	1.34	1.50	1.61	1.72	1.93	2.15	2.31	2.42	2.68
345	1.11	1.38	1.55	1.66	1.77	1.99	2.21	2.38	2.49	2.76
350	1.14	1.42	1.59	1.71	1.82	2.05	2.28	2.45	2.56	2.85
355	1.17	1.46	1.64	1.76	1.87	2.11	2.34	2.52	2.63	2.93
360	1.20	1.51	1.69	1.81	1.93	2.17	2.41	2.59	2.71	3.01

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 400fps, using 0.20g BB resulting in an upper limit of 1.49j.

Velocity	BB Weight (Grams)
FPS	0.20	0.25	0.28	0.30	0.32	0.36	0.40	0.43	0.45	0.50
250	0.58	0.73	0.81	0.87	0.93	1.05	1.16	1.25	1.31	1.45
260	0.63	0.79	0.88	0.94	1.00	1.13	1.26	1.35	1.41	1.57
270	0.68	0.85	0.95	1.02	1.08	1.22	1.35	1.46	1.52	1.69
280	0.73	0.91	1.02	1.09	1.17	1.31	1.46	1.57	1.64	1.82
290	0.78	0.98	1.09	1.17	1.25	1.41	1.56	1.68	1.76	1.95
300	0.84	1.05	1.17	1.25	1.34	1.51	1.67	1.80	1.88	2.09
310	0.89	1.12	1.25	1.34	1.43	1.61	1.79	1.92	2.01	2.23
320	0.95	1.19	1.33	1.43	1.52	1.71	1.90	2.05	2.14	2.38
330	1.01	1.26	1.42	1.52	1.62	1.82	2.02	2.18	2.28	2.53
340	1.07	1.34	1.50	1.61	1.72	1.93	2.15	2.31	2.42	2.68
350	1.14	1.42	1.59	1.71	1.82	2.05	2.28	2.45	2.56	2.85
360	1.20	1.51	1.69	1.81	1.93	2.17	2.41	2.59	2.71	3.01
370	1.27	1.59	1.78	1.91	2.03	2.29	2.54	2.73	2.86	3.18
380	1.34	1.68	1.88	2.01	2.15	2.41	2.68	2.88	3.02	3.35
390	1.41	1.77	1.98	2.12	2.26	2.54	2.83	3.04	3.18	3.53
400	1.49	1.86	2.08	2.23	2.38	2.68	2.97	3.20	3.34	3.72
410	1.56	1.95	2.19	2.34	2.50	2.81	3.12	3.36	3.51	3.90

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 500fps, using 0.20g BB resulting in an upper limit of 2.32j.

Velocity	BB Weight (Grams)
FPS	0.20	0.25	0.28	0.30	0.32	0.36	0.40	0.43	0.45	0.50
250	0.58	0.73	0.81	0.87	0.93	1.05	1.16	1.25	1.31	1.45
260	0.63	0.79	0.88	0.94	1.00	1.13	1.26	1.35	1.41	1.57
270	0.68	0.85	0.95	1.02	1.08	1.22	1.35	1.46	1.52	1.69
280	0.73	0.91	1.02	1.09	1.17	1.31	1.46	1.57	1.64	1.82
290	0.78	0.98	1.09	1.17	1.25	1.41	1.56	1.68	1.76	1.95
300	0.84	1.05	1.17	1.25	1.34	1.51	1.67	1.80	1.88	2.09
310	0.89	1.12	1.25	1.34	1.43	1.61	1.79	1.92	2.01	2.23
320	0.95	1.19	1.33	1.43	1.52	1.71	1.90	2.05	2.14	2.38
330	1.01	1.26	1.42	1.52	1.62	1.82	2.02	2.18	2.28	2.53
340	1.07	1.34	1.50	1.61	1.72	1.93	2.15	2.31	2.42	2.68
350	1.14	1.42	1.59	1.71	1.82	2.05	2.28	2.45	2.56	2.85
360	1.20	1.51	1.69	1.81	1.93	2.17	2.41	2.59	2.71	3.01
370	1.27	1.59	1.78	1.91	2.03	2.29	2.54	2.73	2.86	3.18
380	1.34	1.68	1.88	2.01	2.15	2.41	2.68	2.88	3.02	3.35
390	1.41	1.77	1.98	2.12	2.26	2.54	2.83	3.04	3.18	3.53
400	1.49	1.86	2.08	2.23	2.38	2.68	2.97	3.20	3.34	3.72
410	1.56	1.95	2.19	2.34	2.50	2.81	3.12	3.36	3.51	3.90
420	1.64	2.05	2.29	2.46	2.62	2.95	3.28	3.52	3.69	4.10
430	1.72	2.15	2.40	2.58	2.75	3.09	3.44	3.69	3.86	4.29
440	1.80	2.25	2.52	2.70	2.88	3.24	3.60	3.87	4.05	4.50
450	1.88	2.35	2.63	2.82	3.01	3.39	3.76	4.04	4.23	4.70
460	1.97	2.46	2.75	2.95	3.15	3.54	3.93	4.23	4.42	4.91
470	2.05	2.57	2.87	3.08	3.28	3.69	4.10	4.41	4.62	5.13
480	2.14	2.68	3.00	3.21	3.42	3.85	4.28	4.60	4.82	5.35
490	2.23	2.79	3.12	3.35	3.57	4.02	4.46	4.80	5.02	5.58
500	2.32	2.90	3.25	3.48	3.72	4.18	4.65	4.99	5.23	5.81
510	2.42	3.02	3.38	3.62	3.87	4.35	4.83	5.20	5.44	6.04
